S2800 AUTO Oscilloscope
No Pic

PARTS & ACCESSORIES

S2800  AUTO Oscilloscope
Price $449.99USD

FEATURES
                   Dual Channel and Auto Calibration
                    DC to 1MHz
                    Sampling Time Dual CH:25 Ms/S
                                              Single CH:50Ms/S
                    Automatic Triggering
                    Roll and Single Shot Mode
                    TRMS DMM Function
                    45 Shot  Waveform and Setup  Memories
                    Extra Bright Back Light Display
                    DC or AC 600V Peak
                    RS232C Interface
                    Display Type: Super-Twist 132 * 128 Pixel


SPECIFICATIONS
Oscilloscope Function
Horizontal
Sample Rate 50 MSPS(Single CH)
25 MSPS(Dual CH)

Record Lengh

512 in Single Shot Mode and
256 in all Other Modes

Sample/Div

25
Update Rate Real Time

Modes

Sigle Shot,Roll,Normal
Accuracy 0.01%
Sweep Rate 1uS to 5S in 1 ,2,5 Sequence
Triggering
Type Internal,External

Coupling

AC,DC

Slop

↑or↓Edge

Internal Sensitivity

2/20 Division
Vertical
Bandwidth DC-1MHz

Resolution

8Bit

Channel

Dual
Coupling AC,DC

Input Impedance

1MΩ
Accuracy 3%
Max.Input Volts DC or AC 600Vp
Volt/Division 0.5V-500V in
1,2,5 Sequence
Other
Waveform Memory 8 Shots

Reference Waveform

45 Shots
Digital Multimeter Function

DC V

Range

Resolution

Accuracy

Impedance

5V

0.001

  ±(0.3%+3)

1MΩ

50V

0.01V

500V

0.1V

  ±(0.5%+5)

1000V

1V

AC V

Range

Resolution

Accuracy

Impedance

50-450Hz

0.45K-5KHz

5K-20KHz

3V

0.001V

  ±(0.75%+5)

±(2%+5)

±(2.5%+5)

  1MΩ

30V

0.01V

300V

0.1V

750V

1V

N/A

OHM

Range

Resolution

Accuracy

Overload Protection

5KΩ

0.001KΩ

  ±(0.5%+5)

  600V DC or AC Peak

50KΩ

0.01KΩ

500KΩ

0.1KΩ

5MΩ

0.001KΩ

 ±(0.75%+10)

Continuity Buzer

  Test Voltage

Threshold

Overload Protection

   1.7V

100 Digits

600V DC or AC Peak
